| TRACTOR TYPE |
|
4 Wheeled Tractor With 4WD |
| ENGINE |
|
|
| MODEL |
|
4105 DC TLWO7D DHT |
| HP CATEGORY |
|
90 HP |
| TYPE |
|
| NO. OF CYLINDER |
|
4 |
| BORE/STROKE (MM) |
|
105/118 |
| DISPLACEMENT (CC) |
|
4087CC |
| COMPRESSION RATIO |
|
18.5:1 |
| RATED ENGINE RPM |
|
2200 rpm ± 25 |
| COOLING SYSTEM |
|
Water Cooled |
| FUEL INJECTION PUMP |
|
Mico Bosch |
| AIR CLEANER |
|
|
| CLUTCH |
|
|
| TYPE |
|
Dual Clutch |
| DIAMETER |
|
|
| TRANSMISSION |
|
| GEAR SPEED(Km/hr) |
|
Kms/Hr. With Rear Tyre Size 18.4x30 |
| L1 |
|
03.22 |
| L2 |
|
04.43 |
| L3 |
|
07.00 |
| L4 |
|
09.49 |
| H1 |
|
12.92 |
| H2 |
|
17.76 |
| H3 |
|
28.05 |
| H4 |
|
38.05 |
| R-L |
|
04.12 |
| R-H |
|
16.55 |
| PTO |
|
| TYPE |
06 Spline, 540 RPM Standard |
| BRAKES |
Heavy Duty, Self Energizing Water Sealed Disc |
|
Brakes with parking Brake For Additional Safety |
| STEERING |
Power Steering |
| HYDRAULIC |
2 Lever, Automatic Position And Draft With Mix Control |
| A. POSITION CONTROL |
To Hold Lower Links at Desired Heights |
| B. AUTOMATIC DRAFT CONTROL |
Maintains uniform Draft |
| C. MIX CONTROL |
For simultaneous use of position and draft controls for optimum field output. |
| HYDRAULIC PUMP |
Double Gear pump ( 12+9.5 CC) delivering 26.4 LPM for |
|
Hyd. Lift & 20.9 LPM for Steering at rated engine speed |
| LINKAGE |
3 Point linkage category II suitable for category II type pins |
| LIFTING CATEGORY |
1600 Kg at end of lower links. |
| ELECTRICAL INSTRUMENT |
12 Volt, 88 AH Battery, Starter Motor Alternator, Hour meter Ammeter |
|
Electrical Temp Gauge, Oil pressure Gauge & Fuel Gauge |
| TYRE |
|
|
| FRONT TYRE |
|
12.4 - 24 |
| REAR TYRE |
|
18.4 - 30 |
| DIMENSIONS |
|
|
| OVERALL LENGTH |
|
4185 MM |
| OVERALL WIDTH |
|
1836 MM |
| OVERALL HEIGHT |
|
2350 MM |
| MIN GROUND CLEARANCE |
|
400 MM |
| WHEEL BASE |
|
2308 MM |
| MIN WEIGHT OF TRACTOR WITH BALLAST(KGS) |
|
3640 |
| Specifications are subject to change without notice |
